JY65E-13R CNC Multi-function 3D High-speed Copper / Aluminum Busbar Bending / Forming Machine
- See More by Copper Busbar Bending Machine
Y65E-13R Busbar bending machine (maximum size of 26.0*7.0mm can be processed) is a multi-functional special machine that integrates all the functions of a 3D bending machine and a spring machine. It adopts camless and rotary design. Independently controlled by multiple sets of servo motors, the busbar bending machine is widely used in conductive bar forming, new energy battery connecting bar, new energy battery module, copper busbar forming, hard bar forming, conductive bar, battery connecting bar, copper bar, bare bar forming, etc. Precise and accurate, fast machine adjustment, stable and reliable.
Equipment Features:
1. Thirteen sets of servo motors independently control eight workstations, including wire feeding, bending, wire rotation, and rapid machine adjustment.
2. Transmission using imported servo motors and precision-grade gears ensures high accuracy, long service life, and high stability.
3. The tool holder adopts parallel heavy-duty double guideway sliders, ensuring high rigidity.
4. The tool holder adopts parallel heavy-duty double guideway sliders, ensuring high rigidity.
5. Simple operation with a user-friendly interface; the computer automatically monitors the overall machine health and provides alerts.
6. High-precision gear manufacturing process of the wire feeding box ensures long-term wire feeding accuracy.
7. Complies with V8 extruded busbar bending technical specifications. The equipment can operate continuously 24 hours a day.
Equipment Parameters:
